MasterAir MA410P
Introducing the MasterAir MA410P
The MasterAir MA410P is the upgraded version of the MasterAir Pro 4, the Pro standard in CPU air cooling design and production from Cooler Master. The Continuous Direct Contact Technology 2.0 (CDC 2.0) increases the surface area of the cooler base by 45%. With the added bonus of the MasterFan 120 Air Balance RGB, making it not only silent and efficient in heat transfer, but also the most vibrant and fun choice when it comes to air cooling. If you are looking for an air cooler based on performance, silence, and quality RGB lighting, the MasterAir MA410P is the perfect cooler for you.
CDC 2.0
4 heatpipes with Continuous Direct Contact Technology 2.0
Comparing to its previous version CDC 1.0.,
CDC 2.0 creates 45% more contact surface area on cooler base by compressing heatpipes together.
It significantly increases heat dissipation capability and outperform its predecessor.
Countless Colors and Effects
With a sturdy MasterFan 120 Air Balance RGB and our wired RGB Controller,
MasterAir MA410P is ready for more than 16.7 million color options
and tons of fun effects to play with
Snap and Play
Intuitive fan bracket design makes upgrading and removing the fan a breeze.
Optional push-pull fan configuration
To avoid dynamic losses and help accelerate heat exhaust, an additional MasterFan 120 Air Balance RGB helps pulling heat away faster from heatsink.
Brightness Color Switch Mode Switch
RGB in the palm of your hand with included Wired RGB Controller C10L
A compact size RGB LED controller that allows you to easily customize your RGB devices without the need for either an RGB capable motherboard or software. With six pre-set modes, seven color options and five brightness levels, you can have the colorful rig you’ve always wanted with just the touch of a button.
Specifications
Product Name |
MasterAir MA410P |
Model |
MAP-T4PN-220PC-R1 |
CPU Socket |
Intel® LGA 2066 / 2011-v3 / 2011 / 1151 / 1150 / 1155 / 1156 / 1366 socket
AMD® AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 socket |
Dimensions (LxWxH) |
84 x 129 x 158.5 mm (3.3 x 5.1 x 6.2 inch) |
Heat Sink Dimensions (LxWxH) |
60 x 116 x 158.5 mm (2.4 x 4.6 x 6.2 inch) |
Heat Sink Material |
4 Heat Pipes / CDC 2.0 / Aluminum Fins |
Heat Sink Weight |
420 g (0.93 lb.) |
Heat Pipes Dimensions |
ø6mm |
Fan Dimensions |
120 x 120 x 25 mm (4.7 x 4.7 x 1 inch) |
Fan Speed |
650 – 2,000 RPM (PWM) ± 10% |
Fan Air Flow |
66.7 CFM (Max) |
Fan Air Pressure |
2.34 mmH2O (Max) |
Fan MTTF |
160,000 hours |
Fan Noise Level |
6 – 30 dBA |
Fan Connector |
4-Pin (PWM) |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.28 A |
Fan Safety Current |
0.37 A |
Fan Power Consumption |
3.36 W |
Warranty |
1 year |
EAN Code |
4719512064009 |
UPC Code |
884102036675 |
